No exposed mounting fasteners when closed. Fastener screw pack includes Custom #12-24 × 7/16"PFHMS U/C S.S.
Supports weights up to 900lbs. 4'0" maximum door width
Symmetrically templated hole pattern. Specify handing on 6'8", 7'2" and for most optional features
Optional features include US32 Bright Polished Stainless (629), custom lengths (specify handing and length in inches), custom hole patterns, plug weld hole pattern, tamper-proof security screws
When installed on a 16 gauge (or heavier) metal frame, hinge reinforcements are not required, nor are they recommended. However, if the frames are equipped with mortise hinge reinforcements, removal is not advised
ANSI/BHMA Standard A156.26 Grade 1
Fire Rating
Classified in accordance with UBC standard 7-2 for positive pressure
20 minutes — wood doors
90 minutes — hollow metal and composite core wood fire doors
