Reduced price! View larger

Kwikset

Kwikset 687BW Belleview Handleset

$140.18

?
?
?
?
?

Details: Kwikset 687BW Belleview Handleset

See Chart Below For Available Interior Pack Finish and Style Combinations.

Choosing a configuration that is not in accordance with this chart will result in a failed order and you will be contacted by a representative to choose viable options or initiate a refund.

Kwikset Signature Series

Finish Option L03 3 5 11P 15 15A 26 26D
Abbey Knob
Brooklane Lever
Cameron Knob
Circa Knob
Commonwealth Lever
Copa Knob
Hancock Knob
Laurel Knob
Lido Lever
Pembroke Lever
Tustin Lever

Kwikset

Finish Option L03 3 5 11P 15 15A 26 26D
Balboa Lever
Cove Knob
Delta Lever
Dorian Lever
Polo Knob
Tylo Knob

Technical Specifications

ADA
No
ANSI Certification
A156.5
Backset
2⅜" or 2¾"
BHMA Certification
Grade 3
Center to Center
5½"
Center to Bottom
8-13⁄32"
Collection
Belleview
Cylinder
5-pin or 5-pin SmartKey
Cross Bore
2⅛"
Door Thickness
1¾"
Edge Bore
1"
Functions Available
Single Cylinder, Double Cylinder, Dummy
Handle Style
Metal Grip
Mount
Sectional
Panic Proof
No
Product Class
Residential
Projection
2-5⁄32"
Style
Transitional

Kwikset's handlesets are designed to look great and function perfectly. With a variety of finishes and designs, the Kwikset 687BW Belleview Single Cylinder Handleset handleset will revolutionize your front door.

Kwikset Knob/Lever Finish Options

Kwikset Signature Series

Polished Brass3Antique Brass5Venetian Bronze11PSatin Nickel15Antique Nickel15APolished Chrome26Satin Chrome26DIron Black514
Abbey Knob✔✔✔
Ashfield Lever✔✔✔✔
Avalon Lever✔✔✔✔
Brooklane Lever✔✔✔
Cameron Knob✔✔✔
Circa Knob✔✔✔✔✔✔
Commonwealth Lever✔✔✔✔✔✔✔✔
Hancock Knob✔✔✔✔✔✔✔✔
Halifax Lever✔✔✔✔✔
Laurel Knob✔✔✔✔✔
Lido Lever✔✔✔✔✔✔
Lisbon Lever✔✔✔✔✔
Milan Lever✔✔✔✔✔
Pembrooke Lever✔✔✔✔✔✔✔
Phoenix Knob✔✔✔✔
Tustin Lever✔✔✔✔✔✔✔✔

Kwikset

Polished Brass3Antique Brass5Venetian Bronze11PSatin Nickel15Antique Nickel15APolished Chrome26Satin Chrome26DIron Black514
Aliso Knob✔✔✔✔
Balboa Lever✔✔✔✔✔✔
Cove Knob✔✔✔✔✔✔
Delta Lever✔✔✔✔✔
Dorian Lever✔✔✔✔✔✔✔
Polo Knob✔✔✔✔✔✔✔
Tylo Knob✔✔✔✔✔

Kwikset SmartKey Cylinder

Kwikset SmartKey

With Kwikset SmartKey you never have to worry about an intruder finding lost or stolen keys again. Utilizing SmartKey technology, you can easily and quickly re-key your locks in three easy steps. Simply insert the functioning key and turn ¼ clockwise, then insert the SmartKey learn tool and remove the functioning key. Finally, insert your new key and ½ turn it counter clockwise and just like that your security is reset. Kwikset prides themselves on creating ANSI Graded bump guard protected high security door hardware you can trust to be drill and pick resistant. Re-key your SmartKey locks as frequently as you wish while maintaining the highest level of security. Choose from our variety of knobs, levers, deadbolts, handlesets, and electronic locks to upgrade your safety and your home.

SmartKey™ provides security that is resistant against torque attacks, passes the most stringent lock picking standard UL 437, par 11.6. and utilizes BumpGuardâ„¢ to prevent lock bumping.

Features of the SmartKey

  • Bump proof and superior pick resistance
  • Secure your home in seconds – SmartKey allows you to re-key your lock in seconds, rendering lost or unreturned keys useless.
  • Advanced protection from kick attacks
  • Highest professional security ANSI/BHMA certified Grade 1

Reasons you will want to re-key

  • Lost, stolen or unreturned keys
  • Recently moved
  • Increase your home's security
  • One-key convenience for all Kwikset locks
  • Remodeling, upgrading or updating

Reasons SmartKey is Superior

Drill Resistance
The lock cylinder uses two steel balls inserted into the front of the key face to resist attack from drilling.
ANSI Grading
SmartKey is available in an ANSI Grade 1 deadbolt - certified the highest level of residential security.
BumpGuard™
Patented side locking bar technology offers improved protection against lock bumping, an attack technique used to defeat conventional pin tumbler locks.
Superior Pick-Resistance
SmartKey locks have passed the most stringent lock-picking standard, UL 437, par. 11.6.

How the Kwikset SmartKey Works

You will need to have your Functioning Key and Learn Tool for this to work.

  • Functioning Key
    Functioning Key
  • Learn Tool
    SmartKey Learn Tool
  • New Key
    New Key
  1. Re-Key Step 1
    Insert the functioning key & make a 1/4 turn clockwise.
  2. Re-Key Step 2
    Insert & remove the SmartKey learn tool, Then remove the functioning key.
  3. Re-Key Step 3
    Insert the new key & turn 1/2 turn counter-clockwise. Done. Your lock is now re-keyed!

Available Model Numbers and Combinations

Model/SKU Attributes
687BW 3 KD Single Cylinder, Polished Brass, Keyed Different
687BW 3 KA Single Cylinder, Polished Brass, Keyed Alike
687BW SMT 3 KD Antique Brass, Single Cylinder With Smart Key, Keyed Different
687BW SMT 3 KA Antique Brass, Single Cylinder With Smart Key, Keyed Alike
689BW 3 KD Double Cylinder, Venetian Bronze, Keyed Different
689BW 3 KA Double Cylinder, Venetian Bronze, Keyed Alike
689BW SMT 3 KD Satin Nickel, Double Cylinder With Smart Key, Keyed Different
689BW SMT 3 KA Satin Nickel, Double Cylinder With Smart Key, Keyed Alike
699BW 3 KD Satin Chrome, Dummy, Keyed Different
699BW 3 KA Satin Chrome, Dummy, Keyed Alike
898BW 11P KD Polished Brass, Handle Day, Keyed Different
898BW 11P KA Polished Brass, Handle Day, Keyed Alike
