Locinox MAMMOTH180 Hydraulic 180 Degree Gate Closer & Hinge

MAMMOTH180-

$576.86

Details: Locinox MAMMOTH180 Hydraulic 180 Degree Gate Closer & Hinge

Hydraulic swing gate closer and bearing hinge in one. An elegantly designed self-closing hinge that opens smoothly and closes consistently gates up to 330 lbs and this regardless of the outside temperatures (patented system). Force, closing speed and closing action (snap shut) are all individually adjustable according to your needs. Probably the best self-closing hinge on the market!

Specifications

  • Self-closing hinge with patented hydraulic damping
  • Adjustable closing speed & closing pressure
  • Fast and easy installation with Quick-Fix
  • Adjustable closing action for perfect closing, smooth or snap shut
  • For left and right opening gates
  • Opening angle: 180°
  • Powdercoated aluminium casing
  • Double stainless steel bearing
  • 2-dimensionally adjustable, Gap & Ht × 3/4"
  • Easy to open: Max opening force 3.5 lbs
  • Conforms to all regulations regarding max allowed forces to open gates
  • Ideal in combination with magnetic and mechanical locks
  • Bottom Dino hinge included (Double stainless bearing)
  • Especially designed for exterior use: rain & frost-proof
  • Aesthetic design
  • Burglar proof and anti-theft
  • Closing force over the full 180° opening angle
  • Closing speed unaffected by temperature changes
  • For gates up to 330 lbs. and 5 ft. wide
  • Tested at 500.000 movements
  • Tested from -22° F to 160°F
  • Distance between post and gate : from 3/8" to 1-10/16"

Installation Instructions

Available Model Numbers and Combinations

Model/SKU Attributes
MAMMOTH180-ZILVCLB-MAMMOTH Silver,
MAMMOTH180-9005CLB-MAMMOTH Flat Black,
MAMMOTHHD-ZILV Silver,
MAMMOTHHD-9005 Flat Black,
MAMMOTH180-ZILV Silver,
MAMMOTH180-9005 Flat Black,
