Markar FS101 Full Surface 1/8" Inset Pin and Barrel Hinge

FS101

$870.37

Details: Markar FS101 Full Surface 1/8" Inset Pin and Barrel Hinge

  • 3/16" diameter stainless steel barrel type hinge pin (rod). Medical bearings. Aluminum end pins
  • No exposed mounting fasteners. Universal screw pack includes 1/4-14 × 3/4 Security TORX TEK Screws
  • 6063-T6 aluminum alloy. Standard finishes: Clear Anodized (628) and Dark Bronze Anodized (313). Optional finishes available.
  • ANSI/BHMA Standard A156.26 Grade 2

Finishes

  • Black Anodized (315)
  • Scratch-Resistant Powder Coated Paint
  • Light Bronze Anodized (311)

Fasteners

  • 1 5/8" aluminum sleeve bolts
  • Tamper-proof security screws

Other Features

  • Custom lengths- specify in inches
  • Custom hole pattern
  • Dutch door hinges - suffix "DDP"
  • Hospital tips - suffix "HT"
  • Lead lined covers with 4 lbs. lead lining - suffix "LL"

Electrical Modifications

  • Electrical Transfer Access Prep - suffix ETAP
  • ElectroLynx® EL4 (4 wire), EL8 (8 wire), EL12 (12 wire)
  • PoE (9 wire)

Available Model Numbers and Combinations

Model/SKU Attributes
FS101C-79 79-3/16", Clear Anodized
FS101C-83 83-1/8", Clear Anodized
FS101C-85 Clear Anodized, 85-1/8"
FS101C-95 95", Clear Anodized
FS101D-79 79-3/16", Bronze Anodized
FS101D-83 83-1/8", Bronze Anodized
FS101D-85 Bronze Anodized, 85-1/8"
FS101D-95 95", Bronze Anodized
