> >>Ojmar 233 Pulse Electronic Lock

Ojmar 233 Pulse Electronic Lock

$256.80

?

Details: Ojmar 233 Pulse Electronic Lock

OTS Pulse is an online real-time wireless electronic locking system with RFID and BLE technology mainly intended for sports, school, offices and leisure facilities. Lock is fully controlled via wireless from Ojmar´s cloud software, allowing to reconfigure and assign permissions remotely. Lock will ask for permission to operate to the central management and will operate once answer is received. An offline lock is added in case network fells down, allowing operation in standalone mode and storing all the information, in order to send it back to the cloud software once communication is reestablished.

Features

  • Real-time analytics
  • Space optimisation via heat mapping
  • Unrivalled flexibility, multiple user modes
  • Cloud-based remote facility management
  • Multi-technology platforms: RFID and BLE for mobile use
  • Lockers on arrival booking functionality via Ojmar app
  • API ready
  • Protection against internal impact: IK9.
  • Display without LED.
  • Dimensions; 109,5 × 35 × 118 mm.

Multitechnology

  • ISO/IEC 14443
  • Mifare Classic 1K/4K 4B and 7B UID
  • Mifare Ultralight and Ultralight C
  • Mifare DESFire EV1 & EV2
  • ISO 15693
  • HID® iClass
  • HID® Seos
  • Bluetooth®
  • NFC

Ciber Security

  • Encrypted communications.
  • The web connection is encrypted via Https with an SSL certificate.
  • Each incoming connection uses its own dynamically encrypted protocol.

Extraordinary battery life

  • Up to 8 years

Enhanced automatic data transfer

  • Battery status
  • Lock status
  • Traceability & lock use: time, user

Intelligent Maintenance & Backups

  • Battery & lock status.
  • Events log.
  • Keeps the configuration after battery change.
  • Low battery indicator.
  • FW update via network.
  • Emergency power supply from the knob.
  • Configurable usage reports.
  • Offline mode in case of gateway failure: Data storage and automatic sending after network recovery.

Configuration

  • Fully configurable by the Facility manager.
  • Automatic connection of the locks to the Ojmar´s cloud software.
  • Real-time configuration and assignment of access permissions via Ojmar´s cloud software.
  • Integration with third parties software via SDK
  • Automatic openings

Credentials

  • RFID Bracelets
  • RFID Cards
  • Smartphone Credentials: App

Specifications

Power supply
4 alkaline batteries VARTA Type AA
Battery life
Up to 8 years
Low battery detection
Automatically notified in real time
Comunication interface
Protocol 2.4 GHz propietary (IEEE 802.15.4)
Temperature range
-10ºC/ 42ºC
Protection against solid and liquid bodies
IP55
Protection against external impact
IK7
Protection against internal impact
IK9
Display led
LED (Red, amber & green)

Gateway

  • Protocol 2.4 GHz propietary (IEEE 802.15.4)
  • No of maximum connections up to 500 (depending on the layout of the installation)
  • Reading distance Up to 50m (depending on the layout of the installation)
  • Communication standard LAN Ethernet RJ-45, USB
  • Ethernet DHCP
  • Power Supply 8-30VDC Output, 12W min.
  • Supports IEEE 802.11 PoE

Downloads

OTS Pulse - Smart Locker Lock System
