Sargent 590 Series Heavy Duty Overhead Surface Mount Door Holder

590

$534.11

Details: Sargent 590 Series Heavy Duty Overhead Surface Mount Door Holder

SARGENT overhead stops/holders are designed to protect the door and hardware from the abuse commonly found in commercial and institutional applications. The Surface application is for exterior and interior single acting doors. Two types to choose from: 'H' Holder, Stops and holds door open, and 'S' Stop, stops door only. All the holders/stops are installed for a particular degree of hold open or stop ranging from 85 degrees to 110 degrees. Attention to detail and rugged design has made the SARGENT line of overhead stops and holders the premier door control products in the industry today.

Features

Features & Benefits

  • Sargent 590 Series Door Holders and Stops are made from rugged, extruded bronze.
  • All holders/stops are installed for a particular degree of hold open or stop ranging from 85 to 110 degrees.
  • Surface application for exterior and interior single acting doors
  • two types to choose from: "H" Holder: stops and holds doors open "S" Stop:stops door only
  • ANSI A156.8 Grade 1 Compliant.
  • SARGENT 590 series stops are UL &10C classified by Underwriter Laboratories as Miscellaneous Fire Door Accessories. note: Door stops are not fire rated. The door and frame carry the fire rating

Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.

  • Hold open models: Convenient knob provides simple "on-off" control of hold-open feature and has an adjustable release tension

Accessories (Shims)

  • Optional solid bronze 1/4" thick jamb bracket shims for use with frames with blade stops
  • Order as required by 21-0104 × finish with screws listed below

Machine Screws

  • Used with above 590 shims up to 3/4" thick. 01-3454 × finish, 4 required. (1/4-20 × 1-1/4")
  • Standard screw pack for 1-3/4" to 2" door. 21-2302 × finish

Specifications

For Doors
Exterior and interior doors from 24" to 60" wide* and for doors 1-3/4"to 2" thick standard. Available for doors up to 3-1/4" thick, use 31-option and specify thickness
Fasteners
Wood screws, machine screws, through-bolts, Mortise nuts supplied as standard for 1-3/4"— 2" thick doors. For doors more than 2" and less than 3-1/4", use 31— option and specify thickness
Options
31 — option: Longer fasteners for doors up to 3-1/4" thick, specify thickness. Example: (31-597H × 26D × 3" thick) 36 — Prefix Torx security machine screws for all exposed screws on all doors up to 2" thick. 6 per holder/stop

Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.

Ideally Suited For

  • Exterior Doors
  • Highly Abused Interior Doors
  • office Buildings
  • Public Housing

Available Model Numbers and Combinations

Model/SKU Attributes
59036-597Sx 15 Included, 24" - 32 - 1/2", Stop Only, Satin Nickel
59036-597Sx 20D Included, 24" - 32 - 1/2", Stop Only, Statuary Dark Bronze
59036-597Sx 26 Included, 24" - 32 - 1/2", Stop Only, Bright Chrome
59036-597Sx 26D Included, 24" - 32 - 1/2", Stop Only, Satin Chrome
59036-597Sx CPC Included, 24" - 32 - 1/2", Stop Only, Clear Powder Coat
59036-597Sx BSP Included, 24" - 32 - 1/2", Stop Only, Black Suede Powder Coat
59036-597Sx WSP Included, 24" - 32 - 1/2", Stop Only, White Suede Powder Coat
59036-598Hx EB Included, 32-5/8" – 39-1/8", Stop w/ Hold Open, Bronze Powder Coated (10B)
59036-598Hx EN Included, 32-5/8" – 39-1/8", Stop w/ Hold Open, Aluminum Powder Coated
59036-598Hx ED Included, 32-5/8" – 39-1/8", Stop w/ Hold Open, Black Powder coated
59036-598Hx EAB Included, 32-5/8" – 39-1/8", Stop w/ Hold Open, Brass Powder Coated
59036-598Hx EP Included, 32-5/8" – 39-1/8", Stop w/ Hold Open, Bronze Powder Coated (10)
59036-598Hx 03 Included, 32-5/8" – 39-1/8", Stop w/ Hold Open, Bright Brass
59036-598Hx 04 Included, 32-5/8" – 39-1/8", Stop w/ Hold Open, Satin Brass
59036-598Hx 09 Included, 32-5/8" – 39-1/8", Stop w/ Hold Open, Bright Bronze
