Details: Best 9KM IDH MAX Cylindrical Lock, Single Keyed

The IDH MAx offers convenience and efficiency for your electrified lock applications. Instead of separately installing reader devices, electrified strikes, door contacts and request-to-exit devices, you can now install just the IDH MAx in cylindrical or mortise lock applications. With IDH MAx, all of the formerly separate equipment needed to control access are self-contained in a single installation, drastically reducing the complexity of multiple wire runs. There are two IDH MAx options available, 9KM IDH Max and 40HM IDH Max.

Features

Integrated Components - IDH Max integrates multiple components into one escutcheon for easier usage and more streamlined aesthetic. Instead of multiple visible pieces installed around the door, with IDH Max you only see one streamlined lockset.
Convenient Compatibility - The IDH Max Series is compatible with most access control systems.
Efficient Design - Rather than installing separate readers, strikes, and other related equipment, IDH Max only has one lockset and one connector and is quick to connect.
Easy Installation - With only one lock case and one connector, installing the IDH Max is quick and easy.
Simple Maintenance - Fewer exposed components make field maintenance on the IDH Max Series simple, and reduce the possibility of part failure.
Heavy-Duty Performance - BEST's experienced engineers designed the IDH Max Series for heavy duty performance. The design protects internal lock parts from damage and failure, and uncompromised materials ensure long-term performance.
Enhanced Durability - Constructed from highly durable materials, the IDH Max Series performs in both indoor and outdoor applications. Enhancements like oil-impregnated stainless steel in the latch bolt reduce wear and tear to the lock.
Easy Integration - Allows fast integration into many access control systems.

Specifications

Materials: Internal parts are brass, zinc or corrosion-treated steel.
Chassis: 2-1/16" diameter to fit 2-1/8" diameter hole in door.
Strike: Brass, bronze, or stainless steel base material; STK 2-3/4" H standard, S3 4-7/8" H., Fits standard door frame cut out as specified in ANSI A115.1. Strike box supplied as standard.
Backset: 2-3/4" standard, 3-3/4" and 5" available.
Door Thickness: Standard lock configuration designed for doors 1-3/4" - 2- 1/4" thick.
Installation: Lock dimensions requires modified door prep ANSI A156.2 Series 4000, Grade 1 to mount housing.
Latchbolt: 9/16" throw.
Escutcheons: 10-1/2" H x 3-5/16" W x 1" D (1" at the top, sloping down to 3/4" at the bottom).
Knobs: Diameter: 2-1/8" Projection on door: 2-7/8"
Lever handle: Made from high-quality zinc alloy. Body is approximately 1-5/8" in diameter: Handle is approximately 4-3/4" in length (from center-line of chassis). Lever styles 14 and 15 return to a minimum of 1/2" of door surface. Lever 16 does not return

Applications

Healthcare
Government

Downloads

W&M Series Catalog

Best Access Warranty

Available Model Numbers and Combinations

Model/SKU	Attributes
9KM3 7 S3690	2-3/4", ANSI, Dark Bronze
9KM3 7 S3 626AM	2-3/4", ANSI, Satin Chrome (Antimicrobial)
9KM3 7 S3606	2-3/4", ANSI, Satin Brass
9KM3 7 S3612	2-3/4", ANSI, Satin Bronze
9KM3 7 S3613	2-3/4", ANSI, Oxidized Satin Bronze
9KM3 7 S3619	2-3/4", ANSI, Satin Nickel
9KM3 7 S3622	2-3/4", ANSI, Flat Black
9KM3 7 S3605	2-3/4", ANSI, Bright Brass
9KM3 7 S3611	2-3/4", ANSI, Bright Bronze
9KM3 7 S3625	2-3/4", ANSI, Bright Chrome
9KM4 7 S3626	3-3/4", ANSI, Satin Chrome
9KM4 7 S3690	3-3/4", ANSI, Dark Bronze
9KM4 7 S3 626AM	3-3/4", ANSI, Satin Chrome (Antimicrobial)
9KM4 7 S3606	3-3/4", ANSI, Satin Brass
9KM4 7 S3612	3-3/4", ANSI, Satin Bronze
