Details: Markar FS201 Full Surface 1/8" Inset Pin & Barrel Hinge, Finish-Zinc Plated Steel

• 3/16" diameter stainless steel barrel type hinge pin (rod). Medical bearings. Stainless steel end pins
• No exposed mounting fasteners. Universal screw pack includes 1/4-14 × 3/4 Security TORX TEK Screws
• Heavy-duty 14 gauge 1012 carbon steel. Zinc plated finish
• ANSI/BHMA Standard A156.26 Grade 1

Fire Rating

• Classified in accordance with UBC standard 7-2 for positive pressure
• 20 minutes — wood doors
• 90 minutes — hollow metal and composite core wood fire doors
• 3 hours — hollow metal doors mounted singly

Finishes

• Scratch-Resistant Powder Coated Paint

Fasteners

• 1 5/8" S.S. sleeve bolts
• Tamper-proof security sCustom lengths- specify in inches

Other Features

• Custom lengths- specify in inches
• Dutch door hinges - suffix "DDP"
• Hospital tips - suffix "HT"
• Lead lined covers with 4 lbs. lead lining - suffix "LL"
