NGP 415 Half Saddle Threshold
415
Details: NGP 415 Half Saddle Threshold
Aluminum Carpet Edge, 3/8" × 2-1/2"
Product Features
- Aluminum alloy 6063, T5 temper
- 4" wide × 1/4" tall
- Fluted top
- Typical wall thickness .125"
- Weight: .51 lbs./ft.
- #10 × 1-1/2" FH zinc plated wood screws included. Dark bronze supplied with DKB thresholds
- Mill finish
Certifications
- ADA COMPLIANT. Barrier Free Thresholds meet the requirements of the ADA Standard for Accessible Design and ICC/ANSI A117.1 Accessible and Usable Buildings and Facilities.
- CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
- POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
- ANSI/BHMA CERTIFIED. Certified thresholds comply with American National Standard for Thresholds ANSI/BHMA A156.21 1,000 lb. load test and are listed in the BHMA Certified Products Directory.
Options
- Slip resistant SIA finish
Downloads
Thresholds Cross Reference
Available Model Numbers and Combinations
| Model/SKU | Attributes |
|---|---|
| 415-1 | Mill Aluminum, 1' |
| 415-2 | Mill Aluminum, 2' |
| 415-3 | 3', Mill Aluminum |
| 415-4 | Mill Aluminum, 4' |
| 415-5 | Mill Aluminum, 5' |
| 415-6 | Mill Aluminum, 6' |
| 415-7 | Mill Aluminum, 7' |
| 415-8 | Mill Aluminum, 8' |
| 415-9 | Mill Aluminum, 9' |
| 415DKB-1 | Dark Bronze, 1' |
| 415DKB-2 | Dark Bronze, 2' |
| 415DKB-3 | 3', Dark Bronze |
| 415DKB-4 | Dark Bronze, 4' |
| 415DKB-5 | Dark Bronze, 5' |
| 415DKB-6 | Dark Bronze, 6' |
