Details: RCI 0162 0 Series 3/4" Rim Strikes

0162 Ships SAME BUSINESS DAY (699-006)

STANDARD FEATURES:

No frame cutting required - surface mounted
Higher grade stainless steel ensures superior keeper strength
Compatible with most major exit devices
Accommodates exit devices with latch projections from ½" to ¾" (13mm - 19mm)
Ensure proper latch alignment with horizontal adjustment up to ¼" (6.4mm) to compensate for door misalignments
Field selectable voltage input -12 or 24VDC and 12 to 24VAC (even 11 to 16VAC)
Horizontal solenoid prevents manipulation from vibration
Modular plug-in wire connectors
Selectively brushed stainless steel finish
Non-handed
Hex socket head cap screws for added support and tamper resistance
Mounting spacer included to provide enhanced latch engagement
Tamper resistant
Conventional keeper design - promotes even load distribution
Installation tool included (hex key)
Optional latch monitor

Specifications

Model: 0162,0162LM,F0162,F0162M Mode: Fail Secure

Volts	Current	Duty	Amps	Ohms
12V	AC	Intermittent	0.33	22
12V	DC	Continuous	0.50	22
24V	AC	Intermittent	0.64	22
24V	DC	Continuous	0.24	89
11-16V	AC	Intermittent	0.32-0.50	22

AC = Alternating Current
DC = Direct Current

Intermittent Duty = Energized less than 1 min. with Duty Ratio 1:5
Continuous Duty = Energized 1 min. or more
